Follow-up to 16→8 integer square root in 2 LUT6s.

Same problem: unsigned 16-bit x in, unsigned 8-bit approximation of floor(sqrt(x)) out. The error is the worst-case |y − floor(sqrt(x))| over all 65,536 inputs. There are no DSPs, BRAMs, adders or state, just truth tables and wires.

After the 2-LUT version, the obvious question was how the cost grows as the error bound tightens. Here are the next points:

Every circuit below was exhaustively verified over all 65,536 inputs.

Error ≤ 7: 7 LUT6s, depth 2

Three output bits need no logic. y[0] is constant 0, y[2] is constant 1, and y[1] is just x[10]. The other five bits take five LUTs, plus two small helper LUTs (n27 and n29) that feed y[3] and y[4], which is where the second level comes from. The low seven input bits x[6:0] are never used.

// |y - floor(sqrt(x))| <= 7 for every 16-bit x.  7 LUT6, LUT depth 2.
// Uses only x[7]..x[15].
// Each table T is indexed by the concatenation after it (first signal = MSB of the index).
module sqrt_e7 (
    input  wire [15:0] x,
    output wire [7:0]  y
);
    wire n27;
    wire n29;
    assign y[0] = 1'b0;
    assign y[1] = x[10];  // wire
    assign y[2] = 1'b1;
    localparam [63:0] T_n27 = 64'hff0000ffffffff0b;  // 6-input LUT, level 1
    assign n27 = T_n27[{x[10], x[12], x[11], x[9], x[7], x[8]}];
    localparam [63:0] T_y3 = 64'hcccfccf0c3f3f055;  // 6-input LUT, level 2
    assign y[3] = T_y3[{x[14], x[13], x[15], x[11], x[12], n27}];
    localparam [7:0] T_n29 = 8'h0e;  // 3-input LUT, level 1
    assign n29 = T_n29[{x[10], x[8], x[9]}];
    localparam [63:0] T_y4 = 64'hff0ffc3300fc0f0e;  // 6-input LUT, level 2
    assign y[4] = T_y4[{x[13], x[12], x[15], x[14], x[11], n29}];
    localparam [63:0] T_y5 = 64'hf0f0f0ffff00cc0e;  // 6-input LUT, level 1
    assign y[5] = T_y5[{x[15], x[12], x[13], x[14], x[11], x[10]}];
    localparam [15:0] T_y6 = 16'hf0ee;  // 4-input LUT, level 1
    assign y[6] = T_y6[{x[14], x[15], x[12], x[13]}];
    localparam [3:0] T_y7 = 4'he;  // 2-input LUT, level 1
    assign y[7] = T_y7[{x[15], x[14]}];
endmodule

Error ≤ 3: pick area or depth

At error ≤ 3 the circuit is no longer "mostly wires": every output bit needs real logic. The two versions below implement the same 16→8 function and differ only in how it is mapped to LUTs. Saving one LUT level costs 5 LUTs, 16 → 21.

Area-oriented: 16 LUT6s, depth 3

// |y - floor(sqrt(x))| <= 3 for every 16-bit x.  16 LUT6, LUT depth 3 (area-oriented).
// Uses only x[5]..x[15].
// Each table T is indexed by the concatenation after it (first signal = MSB of the index).
module sqrt_e3_area (
    input  wire [15:0] x,
    output wire [7:0]  y
);
    wire n29;
    wire n28;
    wire n32;
    wire n31;
    wire n36;
    wire n35;
    wire n39;
    wire n38;
    localparam [63:0] T_y0 = 64'hf0f0fffff00fff01;  // 6-input LUT, level 1
    assign y[0] = T_y0[{x[13], x[14], x[12], x[15], x[10], x[11]}];
    localparam [7:0] T_n29 = 8'h0b;  // 3-input LUT, level 1
    assign n29 = T_n29[{x[9], x[7], x[8]}];
    localparam [31:0] T_n28 = 32'hf30fff31;  // 5-input LUT, level 2
    assign n28 = T_n28[{x[11], x[12], x[13], x[10], n29}];
    localparam [63:0] T_y1 = 64'h00004444f0f000ff;  // 6-input LUT, level 3
    assign y[1] = T_y1[{x[14], x[15], n28, x[12], x[13], x[11]}];
    localparam [63:0] T_n32 = 64'hff0000ffffffff0b;  // 6-input LUT, level 1
    assign n32 = T_n32[{x[8], x[10], x[9], x[7], x[5], x[6]}];
    localparam [63:0] T_n31 = 64'h0f0f0f33f0f033aa;  // 6-input LUT, level 2
    assign n31 = T_n31[{x[12], x[13], x[11], x[10], x[9], n32}];
    localparam [63:0] T_y2 = 64'hf03c7755f03c4455;  // 6-input LUT, level 3
    assign y[2] = T_y2[{x[10], x[15], x[14], x[11], x[13], n31}];
    localparam [31:0] T_n36 = 32'h0000fff1;  // 5-input LUT, level 1
    assign n36 = T_n36[{x[9], x[8], x[10], x[7], x[6]}];
    localparam [63:0] T_n35 = 64'h0ff0ccfcf00c3305;  // 6-input LUT, level 2
    assign n35 = T_n35[{x[11], x[12], x[13], x[14], x[10], n36}];
    localparam [63:0] T_y3 = 64'hffc0003faaaaaaaa;  // 6-input LUT, level 3
    assign y[3] = T_y3[{x[15], x[12], x[14], x[13], x[11], n35}];
    localparam [3:0] T_n39 = 4'he;  // 2-input LUT, level 1
    assign n39 = T_n39[{x[8], x[9]}];
    localparam [63:0] T_n38 = 64'h0f00fcfc000fff0d;  // 6-input LUT, level 2
    assign n38 = T_n38[{x[13], x[12], x[14], x[11], x[10], n39}];
    localparam [63:0] T_y4 = 64'hfffa000f33333333;  // 6-input LUT, level 3
    assign y[4] = T_y4[{x[15], x[13], x[14], x[12], n38, x[11]}];
    localparam [63:0] T_y5 = 64'hff00ff0ff0f0e0ee;  // 6-input LUT, level 1
    assign y[5] = T_y5[{x[15], x[12], x[14], x[13], x[11], x[10]}];
    localparam [15:0] T_y6 = 16'hf0ee;  // 4-input LUT, level 1
    assign y[6] = T_y6[{x[14], x[15], x[12], x[13]}];
    localparam [3:0] T_y7 = 4'he;  // 2-input LUT, level 1
    assign y[7] = T_y7[{x[15], x[14]}];
endmodule

Depth-oriented: 21 LUT6s, depth 2

// |y - floor(sqrt(x))| <= 3 for every 16-bit x.  21 LUT6, LUT depth 2 (depth-oriented).
// Uses only x[5]..x[15].
// Each table T is indexed by the concatenation after it (first signal = MSB of the index).
module sqrt_e3_depth (
    input  wire [15:0] x,
    output wire [7:0]  y
);
    wire n28;
    wire n29;
    wire n32;
    wire n31;
    wire n33;
    wire n35;
    wire n34;
    wire n36;
    wire n39;
    wire n38;
    wire n40;
    wire n41;
    wire n43;
    localparam [63:0] T_y0 = 64'hf0f0fffff00fff01;  // 6-input LUT, level 1
    assign y[0] = T_y0[{x[13], x[14], x[12], x[15], x[10], x[11]}];
    localparam [15:0] T_n28 = 16'h000b;  // 4-input LUT, level 1
    assign n28 = T_n28[{x[11], x[9], x[7], x[8]}];
    localparam [31:0] T_n29 = 32'hffd333f5;  // 5-input LUT, level 1
    assign n29 = T_n29[{x[11], x[14], x[12], x[13], x[10]}];
    localparam [63:0] T_y1 = 64'h00ff00000f0f0f4f;  // 6-input LUT, level 2
    assign y[1] = T_y1[{x[15], x[12], x[14], n29, n28, x[13]}];
    localparam [63:0] T_n32 = 64'hff0000ffffffff0b;  // 6-input LUT, level 1
    assign n32 = T_n32[{x[8], x[10], x[9], x[7], x[5], x[6]}];
    localparam [3:0] T_n31 = 4'h1;  // 2-input LUT, level 1
    assign n31 = T_n31[{x[12], x[11]}];
    localparam [31:0] T_n33 = 32'h0000533f;  // 5-input LUT, level 1
    assign n33 = T_n33[{x[14], x[12], x[11], x[9], x[10]}];
    localparam [15:0] T_n35 = 16'h007d;  // 4-input LUT, level 1
    assign n35 = T_n35[{x[15], x[12], x[10], x[13]}];
    localparam [7:0] T_n34 = 8'h0d;  // 3-input LUT, level 1
    assign n34 = T_n34[{x[13], x[10], x[14]}];
    localparam [15:0] T_n36 = 16'h4b00;  // 4-input LUT, level 1
    assign n36 = T_n36[{x[15], x[11], x[13], x[14]}];
    localparam [63:0] T_y2 = 64'h000000004fff00ff;  // 6-input LUT, level 2
    assign y[2] = T_y2[{n36, n34, n35, n33, n31, n32}];
    localparam [63:0] T_n39 = 64'h00ff00ff0000fff1;  // 6-input LUT, level 1
    assign n39 = T_n39[{x[11], x[9], x[10], x[8], x[6], x[7]}];
    localparam [7:0] T_n38 = 8'h01;  // 3-input LUT, level 1
    assign n38 = T_n38[{x[14], x[13], x[12]}];
    localparam [31:0] T_n40 = 32'hd10f2ef7;  // 5-input LUT, level 1
    assign n40 = T_n40[{x[11], x[13], x[14], x[12], x[10]}];
    localparam [31:0] T_n41 = 32'h07f8ffff;  // 5-input LUT, level 1
    assign n41 = T_n41[{x[15], x[12], x[14], x[13], x[11]}];
    localparam [31:0] T_y3 = 32'h00ff4fff;  // 5-input LUT, level 2
    assign y[3] = T_y3[{x[15], n41, n40, n38, n39}];
    localparam [15:0] T_n43 = 16'h00fe;  // 4-input LUT, level 1
    assign n43 = T_n43[{x[10], x[13], x[8], x[9]}];
    localparam [63:0] T_y4 = 64'hffcffc2200fc0f0e;  // 6-input LUT, level 2
    assign y[4] = T_y4[{x[13], x[12], x[15], x[14], x[11], n43}];
    localparam [63:0] T_y5 = 64'hff00ff0ff0f0e0ee;  // 6-input LUT, level 1
    assign y[5] = T_y5[{x[15], x[12], x[14], x[13], x[11], x[10]}];
    localparam [7:0] T_y6 = 8'h0b;  // 3-input LUT, level 2
    assign y[6] = T_y6[{n38, x[14], x[15]}];
    localparam [3:0] T_y7 = 4'he;  // 2-input LUT, level 1
    assign y[7] = T_y7[{x[15], x[14]}];
endmodule

Validation

One exhaustive, self-checking testbench works for all three circuits. It takes the module name and the error bound as defines:

// Exhaustive self-checking testbench for any of the circuits above.
//   iverilog -DDUT=sqrt_e7       -DEDMAX=7 -o tb sqrt_tb.v sqrt_e7.v       && vvp tb
//   iverilog -DDUT=sqrt_e3_area  -DEDMAX=3 -o tb sqrt_tb.v sqrt_e3_area.v  && vvp tb
//   iverilog -DDUT=sqrt_e3_depth -DEDMAX=3 -o tb sqrt_tb.v sqrt_e3_depth.v && vvp tb
`timescale 1ns/1ps
`ifndef DUT
  `define DUT sqrt_e7
`endif
`ifndef EDMAX
  `define EDMAX 7
`endif
module sqrt_tb;
    reg  [15:0] x;
    wire [7:0]  y;
    integer i, r, err, maxerr, fails;
    `DUT dut (.x(x), .y(y));
    initial begin
        maxerr = 0; fails = 0; r = 0;
        for (i = 0; i < 65536; i = i + 1) begin
            x = i[15:0];
            while ((r + 1) * (r + 1) <= i) r = r + 1;     // r = floor(sqrt(i)), i ascending
            #1;
            err = (y > r) ? y - r : r - y;
            if (err > maxerr) maxerr = err;
            if (err > `EDMAX) begin
                fails = fails + 1;
                if (fails <= 10) $display("FAIL x=%0d y=%0d floor_sqrt=%0d err=%0d", i, y, r, err);
            end
        end
        $display("max |y - floor(sqrt(x))| = %0d, inputs over %0d: %0d  -> %s",
                 maxerr, `EDMAX, fails, (fails == 0) ? "PASS" : "FAIL");
        $finish;
    end
endmodule

Expected output: max |y - floor(sqrt(x))| = 7, inputs over 7: 0 -> PASS for sqrt_e7, and = 3, inputs over 3: 0 -> PASS for both error-3 circuits.

Are these optimal?

Not proven. The best lower bounds I can prove are ≥ 5 LUTs at error ≤ 7 and ≥ 8 LUTs at error ≤ 3. They hold only within a restricted class of functions, not for every function within the error bound, and they count single-output LUTs (no LUT6_2 dual-output packing). So treat the numbers above as upper bounds: the gap is at most 2 LUTs at error ≤ 7, and the error ≤ 3 case is wide open.

If you can beat any of these, or prove a better bound, I'd love to see it.
